Image manipulation with ImageMagick

How to install ImageMagick

You can look at the official documentation or run one of the following commands, based on your operating system.

# Windows
$ winget install ImageMagick.ImageMagick

# macOS
$ brew install imagemagick

A note about Linux

Ubuntu and Debian provide imagemagick packages for version 6, despite the fact that version 7 came out almost 10 years ago. Fedora and Arch Linux both provide packages for version 7.

For simple commands, you can substitute magick with convert and magick mogrify with mogrify to convert a version 7 command to a version 6 command, but I suggest installing an up to date version if possible.

Creating WebP images for your website

magick INPUT.png -resize '128x128>' -quality 100 OUTPUT.webp

Don’t worry about the 128x128 being a square aspect ratio, ImageMagick will never change the aspect ratio of your image without you explicitly requesting it. The > suffix means “down to” that size, so ImageMagick won’t upscale smaller images. You can also use < for “up to” to avoid resizing already large images, and ! to disregard the aspect ratio.

Be sure to include -quality 100 when converting PNG files that contain flat colors or pixel art, since the default with ImageMagick’s WebP conversion is to use lossy encoding for WebP files. You can simply omit the quality flag to get the default quality, or supply any number you want from 1 to 100.

WebP has a massive list of options in ImageMagick if you want even more contorl over the output.

Upscaling pixel art

For nearest-neighbor scaling, you’ll want to use -scale instead of -resize.

magick INPUT.png -scale '200%' -quality 100 OUTPUT.webp

Even though a 200% image is two times the size of the input, if it’s pixel art, it will barely be any larger as a WebP files. Upscaling pixel art to a large size tends to be one of the best ways to retain its visual clarity.

Making an animated image

magick -delay 100 f-1.png f-2.png f-3.png animated.gif

WebP also supports animation:

magick -delay 100 f-1.png f-2.png f-3.png animated.webp

By default the delay is 0, and 100 means 1 second of delay. This lines up with the GIF format using centiseconds as the frame delay value.

Making a favicon.ico

magick favicon-16.png favicon-32.png favicon-192.png favicon.ico

favicon.ico is just a collection of images put in one file, and ImageMagick will automatically put all the images together for you.

Updating an image instead of making a copy

Note: Make sure to make a copy of your images before doing this, or use version control so you can restore changes if you mess up.

$ magick mogrify -scale '200%' *.png

This replace all PNG files with an upscaled version in the current directory.

Removing image metadata

This will remove image metadata, which can include sensitive info like GPS coordinates. Some images metadata is useful, though, so this isn’t always an ideal solution.

$ magick mogrify -strip INPUT.png
# ---or---
$ magick INPUT.png -strip OUTPUT.png

Making a script

Writing these commands repeatedly can get tedious, so I think these tips are best paired with a script to process images for you. I usually write a bash script or Node.js script. I could write an entire blog post about scripting techniques, but I don’t want to right now, so just take this example and do your own research.

bash

#!/usr/bin/env bash
set -eu

cd src
for size in 180 360; do
  magick photo.webp -resize "$size" "photo-${size}.webp"
done

JavaScript

import { spawnSync } from "node:child_process";
import { chdir } from "node:process";

async function main([flag]) {
  chdir("src");
  for (const size of [180, 360]) {
    const ret = spawnSync("magick", [
      "photo.webp",
      "-resize",
      size,
      `photo-${size}.webp`,
    ]);
    if (x.status) {
      console.error("Failed to convert photo.webp");
    }
  }
}

main(process.argv.slice(2));

It doesn’t support as many options, but if you’re using JS then you might prefer sharp since it can be installed through npm and has TypeScript definitions so you can better integrate it into your code.

The sky’s the limit

ImageMagick has an absurd amount of commands. Here’s a small sample:

• -flip → mirror upside-down

• -flop → mirror side-to-side

• -trim → remove a solid colored border around an image

• -crop → crop the image

• -append → join two images top-to-bottom

• +append → join two images side-by-side

ImageMagick also lets you use a special filename magick:logo which is the ImageMagick logo. This is useful if you want to test commands without having an image ready to use. There’s also a few other built-in images you can use.

$ magick magick:logo -fill "#ff0000" -tint 50 red-logo.png

To open the file in your preferred image viewer:

# Windows
$ start FILENAME

# macOS
$ open FILENAME

# Linux
$ xdg-open FILENAME

It might be easier to just drag-and-drop the image into your web browser, so you can refresh the page to see the updates as you refine your commands.
